ETA HR04 24V Submersible Solar Pump System

The ETA HR04 24V Submersible Solar Pump System is a durable, efficient positive-displacement submersible system built for deep wells and off-grid water applications. The HR series uses a helical rotor-and-stator pump coupled to a brushless continuous-duty motor, giving reliable performance in low-yield wells and abrasive conditions thanks to stainless steel internals.

Capable of lifting water up to 400 ft and delivering approximately 1 GPM, the HR04 includes speed control to reduce output when required — very useful for conserving energy on small-yield wells. The pump can run Solar Direct (without batteries) for maximum daytime output, or be automated with a float switch or a pressure tank/switch for pressurized line applications.

Built to be fully serviceable with rugged components and optional surface float capability for dugouts/reservoirs, the HR04 is a versatile choice for ranch, farm, and remote water systems. Warranty: 2 years.

FEATURES

• Positive displacement helical rotor & stator pump
• Brushless continuous-duty motor with speed control
• Stainless steel interior resistant to abrasive wear
• 400 ft max vertical lift with ~1 GPM output
• Operates Solar Direct (no batteries) or with batteries
• Can be controlled by float switch or pressure tank/switch
• Adaptable for well or surface (dugout) applications
• Fully serviceable design for long-term maintenance
• 2-year manufacturer warranty

SYSTEM SPECIFICATIONS
