Motion-Controlled 24V Solar Winter Watering System – Dual 160W Panels, AC Pump, 36″ Bowl
Price Starts At:
$3,995.00
The Motion-Controlled 24V Solar Winter Watering System – AC Pump, 36″ Bowl is the ultimate freeze-proof livestock watering solution, engineered to deliver reliable year-round performance without the need for an artificial heat source. When properly installed and maintained, this system remains fully operational even in extreme cold, ensuring dependable winter hydration for your herd.
This system features a heavy-duty 36″ plastic bowl mounted on a vertical well casing. It operates via a motion-activated submersible pump that fills the bowl only when animals are present. Once the last animal leaves, the bowl automatically drains completely, preventing freeze-up. The system maintains water safely below the frost line and is fed either by gravity from a dugout or through a pressurized line, making it adaptable to different ranch setups.
Powered by a 24V dual 160W solar panel system, this winter watering solution combines efficiency, automation, and durability. Capable of watering up to 600 cow/calf pairs, it is a low-maintenance, high-performance choice for ranchers seeking a dependable cold-weather watering system.
FEATURES
- 100% freeze-proof winter watering system (no heat source required)
- Motion-activated AC pump operates only when animals are present
- 36″ heavy-duty plastic drinking bowl mounted on well casing
- Automatic drainback prevents freezing after use
- Water maintained below frost line for winter reliability
- Supplied via gravity feed or pressurized line
- Waters up to 600 cow/calf pairs efficiently
- Dual 160W solar panels power a 24V system
SYSTEM SPECIFICATIONS
| Specification | Details |
|---|---|
| System Model | Motion-Controlled 24V Solar Winter Watering System |
| System Type | Motion-Activated Solar Watering System (Freeze-Proof) |
| Operating Voltage | 24 VDC |
| Pump Type | AC Submersible Pump with Motion Sensor Activation |
| Solar Configuration | Dual 160W Solar Panels |
| Bowl Size | 36″ Heavy-Duty Plastic Bowl |
| Water Source Options | Gravity Feed or Pressurized Line |
| Freeze Protection | Automatic Drainback to Below Frost Line |
| Capacity | Up to 600 cow/calf pairs |
| Warranty | 2 Years |
INCLUDED SYSTEM COMPONENTS
- 1 × 36″ heavy-duty plastic bowl
- 1 × Standard AC pump with 30 ft of wire
- 1 × AC motion sensor assembly
- 1 × Drainback filter assembly
- 1 × 16′ poly hose (1″ diameter)
- Dual 160W solar panel setup
